Connections 05.05
6-10 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
L1L2L3
L1 L2 L3
NETZ/LINE LAST/LOAD
Connector line filter over large
surface to cabinet housing!
Electronics supply and mains
connection for field supply
Mains connection
Connect the
PE conduct
Seperate filtered and
unfiltered cables
Fig. 1e: Line filter for SIMOREG DC Master 6RA70 electronics power supply
