© 2008 Siemens Energy & Automation, Inc. All Rights Reserved
ACCESS 9340 and 9360 Meters PMCM-9340D-0208
Appendix A—Meter Register List 2/2008
EN–166
Base +19 User Gain Adjustment 0.0001 8000 – 12,000
Analog output user gain adjustment in 100ths of
a percent. Default = 10,000.
Base +20 User Offset Adjustment 0 – ±30000
Analog output user offset adjustment in Bit s of
digital resolution. Default = 0.
Base +21 Reserved Reserved for future development
Base +22
IO Point Diagnostic
Bitmap
0x0000 – 0xFFFF
0 = OK, 1 = Error
Bit 00 = I/O Point diagnostic summary
Bit 01 = Configuration invalid – default value
used
Base +23
Lower Limit Digital
Value
0 – ±32,767
Lower limit of the digital value associated with
the lower limit of the analog output value. Value
based on I/O Point Type.
Base +24
Upper Limit Digital
Value
0 – ±32,767
Upper limit of the digital value associated with
the upper limit of the analog output value. Value
based on I/O Point Type.
Base +25 Present Analog Value 0.01 0 – ±32,767
Analog value expected to be present at the
output terminals of the analog output module.
Base +26
Present Raw
(Register) Value
0 – ±32,767 Value in Reference Register.
Base +27 Calibration Offset 0 – ±32,767
Analog output offset adjustment in bits of digital
resolution.
Base +28
Calibration Gain
(Voltage)
0.0001 8000 – 12,000
Analog output gain adjustment in 100ths of a
percent.
Base +29 Present Digital Value
Table A4: Registers for Inputs and Outputs
Reg Name Scale Units Range Notes
Table A5: Registers for Alarm Logs
Reg Name Scale Units Range Notes
Active Alarm Log
5850
Acknowledge/Relay/Pri
ority Entry 1
Bits 0 -7 = Alarm Number
Bits 8 = Active/Inactive 0=active 1=inactive
Bits 9-11 = Unused
Bits 12-13 = Priority
Bit 14 = relay (1 = association)
Bit 15 = Alarm Acknowledge (1 =
acknowledged)
5851 Unique Identifier 0 – 0xFFFFFFFF
Bits 00 – 07 = Level (0 – 9)
Bits 08 – 15 = Alarm Type
Bits 16 – 31 = Test Register
5853 Label ASCII 16 Characters
5861
Pickup Value for Entry
1
A-F Units/Scale 0 – 32,767 Does not apply to digital or unary alarms
