26.6 Message presentation
The B3Q700 provides 3 text lines within the LCD per alarm message. B3Q580 and
B3Q590/B3Q595 only have a two-line display. The messages at the
B3Q580/590/595 must therefore be reduced to a format of only 2 text lines in order
to meet different requirements. There are 14 display modes available (mode
0...13 selectable via SWE700A).
Mode
Display B3Q580/590/595 Plan ref. no.
on alarm
CSX no. Fault
messages
0
1
nn%<---------- standard text ---------->
<---- last line of customer text --->
●
2
●
3
nn%<---- standard text -----> <-tx1->xxx
<---- last line of customer text --->
● ●
4
●
5
nn%<---------- standard text ---------->
AAAA xx SSSS xxx ZZZZ xxx EEEE xx
● ●
6
● ●
7
nn%<---- standard text -----> <-tx1->xxx
AAAA xx SSSS xxx ZZZZ xxx EEEE xx
● ● ●
8
9
nn%<--------- customer text 1 --------->
<--------- customer text 2 --------->
●
10
●
11
nn%<--- customer text 1 ----> <-tx1->xxx
<--------- customer text 2 --------->
● ●
12
nn%<--------- customer text 1 --------->
<--------- customer text 2 --------->
Special function:
– key acknowledge + reset disabled while remote trans-
mission (RT) is active
– buzzer silenced when RT becomes active
nn%<--- customer text 1 ----> <-tx1->xxx
<--------- customer text 2 --------->
A
13
B
nn%<--------- customer text 1 --------->
<--------- customer text 2 --------->
Special function:
– different display mode
A = on alarm
B = on fault
