B3Q700 Control terminal to FC/FT
76
Siemens Building Technologies 007831_a_en_--.doc
Fire & Security Products 03.2004
20.3 Application
Remote location:
– 24V supplied from the control unit
According to application choose the corresponding Flash program file:
Terminal Utilisation as
Control terminal ’FT700A’ Control terminal and main CPU com-
bined ’FC700A’
B3Q700 FT700A-1 -> CTY00760 international 1) FC700A-1 -> CIY00760 international
1) Default programming at factory by using it as spare part for FC700A, the file CIY00760 must be
downloaded.
The Flash program files are available from the Hotline.
20.4 Functions
Interfaces
– C-Bus → Plug-in terminals ’K5’
– I-Bus → Connector ’ST1’
– 2 x RS232 → Connector ’ST2’
– Parallel indicator panel B3R051, Mimic Display Board K3R072 → Connec-
tor’ST4’
– Emergency operation circuit → Plug-in terminals ’K6’
Control inputs
– External key switch (see Operation enabled)
– Monitoring of autonomous power supply
– Monitoring of Plexiglas door (open / closed)
Operation enabled
– This is normally done via password at the keyboard
– An integrated key switch, (photoelectric) is available as an option, which can
also be used to lock the Plexiglas door (if used).
– Operation can also be enabled by an external key switch
