Siemens FC700A - Important E3 I020 Components

E3I020 RS232 module
50
Siemens Building Technologies 007831_a_en_--.doc
Fire & Security Products 03.2004
12.6 Important components
12
1
Flat cable F20A140 for applica
tion in control unit to B3Q700
connector "ST2"
Flat cable F20A020 for appli
cation in terminal to B3Q700
connector "ST2"
E3I020
E3I020
Installation in control unit FC700A
Application in control terminal FT700A
Connector "ST1":
RS232 (2 x HCMOS level)
Connector "ST2":
for the insertion of a plug-in terminal
block
Plug-in terminals for "ST2"
(supplied with Z1B020)
Metal shield (supplied with Z1B020)
Terminal block
(supplied with Z1I030)
