Siemens FC700A User Manual

K3I050 Mimic Display converter
95
Siemens Building Technologies 007831_a_en_--.doc
Fire & Security Products 03.2004
24.8 Connections
K3I050
1
2
3
4
5
6
Terminal block K1
not used
from E3I040 or previous LON device
+
Supply: 9...45VDC
0V
F1
LON-Bus
to next LON device
Plug-in connector X6
Buzzer output
max. 50mA / 22V
Plug-in connector X7
Operation LED output
Plug-in connector X8
Buzzer off key input
Plug-in connector X9
Lamp test key input
key 'buzzer off'
key 'lamp test'
operation LED
buzzer
Mimic Display board
from E3I040 or previous LON device
supply K3R072, B3R051
Flat cable header (Mini)
ST2
Data bus (via flat cable)
to Mimic Display board K3R072, parallel indicator panel B3R051
internal housing connection
via flat cable
external housing connection
via adapter Z3I530
1
2
3
4
5
6
A
dapter Z3I530
1
Parallel branching
admissible
1
2
3
4
5
6
1
K2
or
to next LON device
K3R072
B3R051
R1
-
12 pin2 pin2 pin2 pin2 pin
