Siemens FC700A - E3 G050 Control Module Contacts; Module Overview and Key Data

E3G050 Control module ”Contacts”
64
Siemens Building Technologies 007831_a_en_--.doc
Fire & Security Products 03.2004
16 E3G050 Control module ”Contacts”
16.1 Overview
 Control module with 8 outputs (volt-free contacts)
 3 changeover and 5 make contacts
 I-Bus module
 Individual function allocation of the output contacts
 Card format 100mm x 200mm
 I-Bus address is set at programming switch ”S3”
16.2 Key data
Output contacts 8
Contact load 24W / 60VDC 1A
Quiescent current at 24V 10mA
E3G050
Terminal block X2 (20 terminals)
- mounted on module chassis
- for the connection of the prefabricated cable to
connection level, or
- for direct connection of the periphery
Card chassis
- mounted on module chassis
