Siemens FC700A - Collective SynoLINE600-Ex Connection Diagram

E3M111 Line module ”SynoLOOP”
43
Siemens Building Technologies 007831_a_en_--.doc
Fire & Security Products 03.2004
10.10 Connection "Collective" SynoLINE600-Ex
L
L
DFB1190
LL
(+)
(-)
SB3
4
3
2
1
Safety barrier
SB3
-+-+-+
L L
DO1101A-Ex
DT110xA-Ex
Explosion hazard area
-
+
-
consult local
regulations!
DM1103+
DMZ1197-AD
24VDC
DF1101-Ex
EOL22Ex
-+-+-+
L L
Base SO620C
1234
GH
GHQRVW
QRVW
Z
DC1192
++
+
+
+
In-/output module
DC1192
SynoLOOP
addressable
collective
SynoLINE600-Ex
APMK=3
KMK=1,6
KMK=1
KMK=1
KMK=6
KMK Load factor for collective elements SynoLINE600-Ex (limited by 25 per
line)
 Details see document 007836
