Siemens FC700A - Conventional SynoLINE300 Connection Diagram

E3M111 Line module ”SynoLOOP”
41
Siemens Building Technologies 007831_a_en_--.doc
Fire & Security Products 03.2004
10.8 Connection "Conventional" SynoLINE300
+-
AI322
AI300
micro terminals
Response indicator
AI322
max. 2 response indicator
Smoke detector
Base SO320
OP320C
HI320A/322A
OH320C
-+-++- -+-++-
Multisensor
smoke detector
AI320
-+-++-
EOL22(Ex)
Heat detector
24VDC
1234
GH
GHQRVW
VW
Z
CB320A
++
+
+
+
Input module
CB320A
Detector bus
SynoLOOP
SynoLINE300
conventional
Base
SO320
Base SO320
APMK=3
KMK=1 KMK=1
+-
+-
KMK Load factor for conventional elements SynoLINE300 (limited by 32 per
line)
 Details see document 007836
