Siemens FC700A User Manual

K3G060 Relay card
91
Siemens Building Technologies 007831_a_en_--.doc
Fire & Security Products 03.2004
23.6 Connections
K3G060
1
2
3
4
+
Plug-in terminals K1
24V
Supply: 9...45VDC
0V
F1
K3R072
K1-1
K1-2
K1-3
to other K3G060
Flat cable header ST1
50 pin
Energizing relays 1......24
from K3R072 'ST11' or 'ST12'
unused
-
Terminal block K2
external potential
(switchable via jumper X1....X24)
1
2
Terminals K3
V+
V-
70
71
X1
Rel.1
1
2
3
max. 30V / 1A
Channel 1
1
2
X24
Rel.24
1
2
3
max. 30V / 1A
Channel 24
12
67
68
X2
Rel.2
1
2
3
Channel 2
max. 30V / 1A
64
65
X3
Rel.3
1
2
3
Channel 3
max. 30V / 1A
Jumpers X1....X24 to tie one side
of the contact either to common
V+ or V-
all jumpers X1....X24 are set to
NEUTRAL at the factory
