Parameterization
9.3 Parameters
3KC ATC6300 transfer control device
142 Manual, 03/2018, L1V30535632002A-01
This menu is divided into 4 sections for the counters CNT1 ... 4.
You can find more information on the user limits in chapter User limit threshold LIMx
(Page 57).
P14
COUNTERS
(CNTn, n =
1…4)
Designation on
ATC display
P14.n.01 Counter source Counter source
– Signal that increments the counter (at the rising edge).
This may involve exceeding a threshold (LIMx) or enabling
an external input (INPx) etc.
OFF OFF
ON
INPx
OUTx
LIMx
P14.n.02 Channel number Channel number (x)
– Number of the channel x, with reference to the previous
1 OFF / 1 ... 99
P14.n.03 Multiplier Multiplier
– Multiplication factor The counted pulses are multiplied by
this factor before they are displayed.
1 1 - 1000
P14.n.04 Divider Divider
– Division factor. The counted pulses are divided by this
factor before they are displayed. If this value is not equal to
1, the counter is shown with two decimal places.
1 1 - 1000
P14.n.05 Description Description of the counter
– Description of the counter. Freely selectable text, 16
CNTn (Text – 16
characters)
P14.n.06 Unit of meas. Unit of measurement
– Measurement unit of the counter. Freely selectable text,
Umn (Text – 6 char-
acters)
P14.n.07 Counter source
reset
Reset source
– Signal that resets the counter. As long as this signal is
enabled, the counter remains at zero.
OFF OFF-ON-INPx-
OUTx-LIMx-
REMx
P14.n.08 Channel number Channel number (x)
– Number of the channel x, with reference to the previous
1 OFF / 1 ... 99
