Error type Error text Meaning Remedy
00110
B
6
D
Wire break
• Signal line to an encoder inter‐
rupted
• Signal line to an actuator in‐
terrupted
• Encoder supply line interrup‐
ted
Correction of the process inter‐
connection
Error on the external circuit (re‐
sistance)
Eliminate errors
Encoder is defect Exchange the encoder
Incorrect encoder type con󹪝gured Correction of the con󹪝guration
Input/output channel is unused
(open)
Deactivation of the "Diagnostic
Group Diagnostics" parameter
for this output channel
Load impedance is too large Use actuator with lower load
impedance
00111
B
7
D
High limit excee‐
ded
Value is above the overrange
• Correction tuning of mod‐
ule/actuator
• Modify measuring range by
means of con󹪝guration
01000
B
8
D
Lower limit excee‐
ded
Value is below the overrange
• Correction tuning of mod‐
ule/actuator
• Modify measuring range by
means of con󹪝guration
01001
B
9
D
Error Encoder signal 󹪞utters Eliminate cause of error
Hardware error in the module Exchange of the module
EMC interference Eliminate cause of error
10001
B
17
D
Encoder- or load
voltage missing
• Supply voltage at the Power
Supply PS missing or too low
• Power Supply PS is faulty
• Check the supply voltage at
the Power Supply PS
• Exchange the Power Supply
PS
10011
B
19
D
HART communica‐
tion error (HART di‐
agnostics)
• HARD 󹪝eld device is not re‐
sponding
• Timing error
• Check the process wiring
• Correction of the con󹪝gura‐
tion
10101
B
21
D
Reference channel
error
• internal reference junction: TC
sensor module defective or
not present
• external reference junction
(RTD): Parameters do not
point to the RTD module
• Exchanging or connecting
the TC Sensor Module
• Correction of the con󹪝gura‐
tion
10110
B
22
D
HART additional
status available
(HART warning)
--- ---
10111
B
23
D
Reserved for HART
(HART warning)
--- ---
11000
B
24
D
Actuator discon‐
nection
Intrinsically safe switching signal
with 4 DO switched on
---
Commissioning and Diagnostics
7.12 Diagnostics with STEP 7 with PROFINET
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 195
