Parameters IM 152-1PN Range of values Default Applicability
Diagnostic interrupts
1
• Disable
• Enable
Disable ET 200iSP
Hardware interrupts
1)
• Disable
• Enable
Disable ET 200iSP
Edge evaluation event enter‐
ing state
2
• Rising edge (0-->1)
• Falling edge (1-->0)
• Channel-speci󹪝c
Rising edge (0-->1) ET 200iSP
Module
Channel
Data format
• SIMATIC S7
SIMATIC S7 ET 200iSP
Noise suppression
• 50 Hz
• 60 Hz
50 Hz ET 200iSP
Temperature unit
• Celsius
• Fahrenheit
Celsius ET 200iSP
Slot reference junction 1 to 2
• None
• 2 to 33
None ET 200iSP
Input reference junction 1 to 4
• RTD on channel 0
• RTD on channel 1
• RTD on channel 2
• RTD on channel 3
RTD on channel 0 ET 200iSP
Advanced diagnostics Yes/No No ET 200iSP
No: 29 bytes for IM 152-1PN
Yes: 96 bytes for IM 152-1PN
Diagnostics frame
Identi󹪝er-related diagnostics Enable / disable Enable ET 200iSP- only IM 152-1PN
Module status Enable / disable Enable ET 200iSP- only IM 152-1PN
Channel-related diagnostics Enable / disable Enable ET 200iSP- only IM 152-1PN
1
It may or may not be possible to edit these parameters, depending on the con󹪝guration tool used.
2
Con󹪝gurable only in HW Con󹪝g and when you operate the ET 200iSP on PROFINET IO and when time stamping is also enabled
for the automation system.
12.1.2 Compatible electronic modules
The following electronic modules can be used with IM 152-1PN:
Module Article number Compatible
8 DI NAMUR 6ES7131-7RF00-0AB0 Yes
4 DO DC23.1V/20mA 6ES7132-7RD00-0AB0 No
4 DO DC23.1V/20mA shut down "H" 6ES7132-7RD01-0AB0 Yes
4 DO DC17.4V/27mA 6ES7132-7RD10-0AB0 No
4 DO DC17.4V/27mA shut down "H" 6ES7132-7RD11-0AB0 Yes
4 DO DC17.4V/40mA 6ES7132-7RD20-0AB0 No
4 DO DC17.4V/40mA shut down "H" 6ES7132-7RD21-0AB0 No
Network interface module
12.1 PROFINET interface module IM 152-1PN
ET 200iSP
282 Operating Instructions, 11/2022, A5E00247483-AK
