I&M Access Default Explanation
SW_REVISION read (4 bytes) Depends on
the product
version
Provides information on the rmware version of the module. If the
rmware version is incremented, then the product version (HW_RE‐
VISION) of the module is incremented as well.
REVISIONS_COUN‐
TER
read (2 bytes) --- Provides information on the assigned changes on the module. Af‐
ter each change, the REVISION_ COUNTER is incremented.
PROFILE_ID
1
read (2 bytes) Not applicable
PROFILE_SPECIF‐
IC_TYPE
1
read (2 bytes) Not applicable
IM_VERSION
1
read (2 bytes) 10
H
Provides information on the version of the I&M (10
H
= Version 1.0).
IM_SUPPORTED
1
read (2 bytes) 3E
H
Provides information on available I&M data (index 1 to 4).
M data 1: Index 2 (data record 45041 for PROFINET, data record 232 for PROFIBUS)
TAG_FUNCTION read / write (32
bytes)
--- Enter a system-wide unique identier for the module here.
TAG_LOCATION read / write (22
bytes)
--- Enter the installation location of the module here.
M data 2: Index 3 (data record 45042 for PROFINET, data record 233 for PROFIBUS)
DEVICE_INSTALL_
DATE
read / write (16
bytes)
--- Enter the installation date of the module here.
M data 3: Index 4 (data record 45043 for PROFINET, data record 234 for PROFIBUS)
DESCRIPTOR read / write (54
bytes)
--- Enter a comment on the module here.
1
The display of this I&M depends on the engineering software.
See also
Project Engineering with GSD File and SIMATIC PDM (Page 161)
PROFINET IO-Base user programming interface (https://support.industry.siemens.com/cs/us/en/
view/26435491)
4.11 Redundant interface modules in the ET 200iSP
4.11.1 Introduction
Properties
You can operate the ET 200iSP station redundantly on the IO controller or on the DP master (e.g.
S7-400H).
Note
In a redundant station, a mixed conguration (IM 152-1PN together with IM 152-1DP) is not
allowed.
Congurations (principle)
4.11 Redundant interface modules in the ET 200iSP
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 79
