A.4.2 Digital output module
Address space digital output module
Table A-20 PIQ for digital output module (S7 format)
PIQ 7 6 5 4 3 2 1 0 Description
QB x Channels 0 to 3 of the output signal
Bit 0: Channel 0 (output DO
0
)
Bit 1: Channel 1 (output DO
1
)
Bit 2: Channel 2 (output DO
2
)
Bit 3: Channel 3 (output DO
3
)
QB x+1 Not occupied
A.4.3 Digital output module 2 DO Relay UC60V/2A
Address space digital output module 2 DO Relay UC60V/2A
Table A-21 PIQ for digital output module 2 DO Relay UC60V/2A (S7 format)
PIQ 7 6 5 4 3 2 1 0 Description
QB x Channels 0 to 1 of the output signal
Bit 0: Channel 0 (output DO
0
)
Bit 1: Channel 1 (output DO
1
)
QB x+1 Not occupied
A.4.4 Analog input modules
Address space analog input modules
Table A-22 PII for analog input modules (S7 format)
PII 7 6 5 4 3 2 1 0 Description
IB x Input value channel 0
IB x+1
IB x+2 Input value channel 1
IB x+3:
IB x+4 Input value channel 2
IB x+5
IB x+6 Input value channel 3
IB x+7
Appendix
A.4 Address space of the inputs and outputs
ET 200iSP
438 Operating Instructions, 11/2022, A5E00247483-AK
