6.5.2 Inserting power supply PS
Installing the Power Supply PS
1. Hang the power supply at the top of the bearing position of the terminal module TM-PS-A.
2. Swivel the Power Supply downwards until it latches on to the terminal module.
3. If your con󹪝guration includes a power supply for redundancy, then repeat steps 1 and 2 on
the TM-PS-B terminal module.


Figure 6-12 Installing the Power Supply PS
CAUTION
Danger of crushing!
Despite its small size, the Power Supply PS weighs 2.7 kg because it is compact. Therefore,
please make sure to hold the Power Supply PS 󹪝rmly in your hand.
Wiring
6.5 Inserting and labeling the power supply, interface module, and electronic modules
ET 200iSP
142 Operating Instructions, 11/2022, A5E00247483-AK
