3.3 Materials and Tools Required to Set Up the Example
Table 3-1 Required materials and tools
Quan
tity
Article Article number (Sie‐
mens)
Required for the con󹪝gura‐
tion variant
PROFINET IO PROFIBUS DP
1 Interface module IM 152-1PN 6ES7152-1BA00-0AB0 YES NO
1 Engineering tool
• Programming device (PG) with Ethernet interface and
RJ45 cable
• Installed software (versions)
– STEP 7 (as of V5.7 SP1 and the current hardware
update of the interface module and electronic mod‐
ules)
– PCS 7 (as of V9.1 SP2 and the current HSP for
ET 200iSP)
Various YES NO
1 Media converter RJ45/FOC with SFP transceiver certi󹪝ed as
intrinsically safe (e.g. SCALANCE X 212-2; see "Optical con‐
nection (https://support.industry.siemens.com/cs/ww/en/
view/109761426)")
Contact your Siemens
representative
YES NO
1 Ethernet cable with RJ45 connector (e.g. "Passive network
components (https://
support.industry.siemens.com/cs/ww/en/view/
84922825)")
YES NO
1 Fiber-optic cable with LC plug (e.g. "Passive network com‐
ponents (https://support.industry.siemens.com/cs/ww/en/
view/84922825)")
YES NO
1 Enclosure for ET 200iSP with Ex e type of protection (for use
of the ET 200iSP in Zone 1 hazardous area)
YES YES
1 Interface module IM 152-1DP 6ES7152-1AA00-0AB0 NO YES
1 Engineering tool
• Programming device (PG) with Ethernet interface, com‐
munications processor such as CP 5611 and PG cable
• Installed software: STEP 7 (as of version 5.4 SP1 and
current hardware update)
Various NO YES
1 RS 485-IS coupler 6ES7972-0AC80-0XA0 NO YES
2 PROFIBUS bus connector (for master and RS 485-IS coupler) 6ES7972-0BB50-0XA0 NO YES
1 PROFIBUS bus connector RS 485-IS including switchable
terminating resistor
6ES7972-0DA60-0XA0 NO YES
1 PROFIBUS DP cable e.g. 6XV1830-0EH10 NO YES
1 SIMATIC S7-300, mounting rail L=160 mm (for RS 485-IS
coupler)
6ES7390-1AB60-0AA0 YES YES
2 SIMATIC S7-300, mounting rail L=480 mm (for ET 200iSP) 6ES7390-1AE80-0AA0 YES YES
1 Terminal module TM-PS-A 6ES7193-7DA10-0AA0 YES YES
1 Terminal module TM-IM/EM with terminating module 6ES7193-7AA00-0AA0 YES YES
2 Terminal module TM-EM/EM 6ES7193-7CA00-0AA0 YES YES
1 Power supply PS DC24V 6ES7138-7EA01-0AA0 YES YES
Commissioning guideline
3.3 Materials and Tools Required to Set Up the Example
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 39
