Table A-23 Example: Input value on channel 0: 61A8
H
(S7 format)
PII 7 6 5 4 3 2 1 0 Description
IB x 61
H
Input value channel 0: 25000
IB x+1 A8
H
A.4.5 Analog output modules
Address space analog output modules
Table A-24 PIQ for analog output modules (S7 format)
PIQ 7 6 5 4 3 2 1 0 Description
QB x Output value channel 0
QB x+1
QB x+2 Output value channel 1
QB x+3
QB x+4 Output value channel 2
QB x+5
QB x+6 Output value channel 3
QB x+7
Table A-25 Example: Output value on channel 0: 61A8
H
(S7 format)
PIQ 7 6 5 4 3 2 1 0 Description
QB x 61
H
Output value channel 0: 25000
QB x+1 A8
H
A.4.6 Analog input modules with HART (4 AI I 2WIRE HART, 4 AI I 4WIRE HART)
Address space of analog input modules with HART (4 AI I 2WIRE HART, 4 AI I 4WIRE HART)
Table A-26 PII for analog input modules with HART (S7 format)
PII 7 6 5 4 3 2 1 0 Analog value
IB x Input value channel 0
IB x+1
IB x+2 Input value channel 1
IB x+3:
IB x+4 Input value channel 2
IB x+5
Appendix
A.4 Address space of the inputs and outputs
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 439
