Siemens SIMATIC ET 200iSP User Manual

The identi󹪝er-related diagnostics for ET 200iSP is con󹪝gured as follows:
Table 7-33 Con󹪝guration of the identi󹪝er-related diagnostics for ET 200iSP
Byte 7 6 5 4 3 2 1 0 Description
Byte 6 0 1 0 0 0 1 1 0 Bit 0 to 5: Length of the identi󹪝er-related diagnostics
including byte 6 (= 6 bytes)
Bit 6 and Bit 7: Code for identi󹪝er-related diagnostics
Byte 7 8 7 6 5 4 2 Entries for IM 152-1DP on slot 2 and modules on slots 4
to 8
Byte 8 16 15 14 13 12 11 10 9 Entries for modules on slot 9 to 16
Byte 9 24 23 22 21 20 19 18 17 Entries for modules on slot 17 to 24
Byte 10 32 31 30 29 28 27 26 25 Entries for modules on slot 25 to 32
Byte 11 35 34 33 Entries for modules on slot 33 to 35
7.13.10 Module status in PROFIBUS
De󹪝nition
The module status indicates the status of the con󹪝gured modules and provides more detailed
information than ID-related diagnostics in terms of the con󹪝guration or indicates a module fault.
The module status begins after the ID-related diagnostics and comprises 13 bytes.
Module Status
The module status for ET 200iSP is con󹪝gured as follows:
Table 7-34 Module status of the ET 200iSP
Byte 7 6 5 4 3 2 1 0 Description
Byte 12 Bit 0 to 5: Length of the module status including byte 12
(=13 byte)
Bit 6 and Bit 7: Code for device-speci󹪝c diagnostics
Byte 13 Status type: Module status
Bit 0 to bit 6: 2
H
= Module status
Bit 7: Code for status message
Byte 14 0
H
Always "0"
Byte 15 0
H
Always "0"
Byte 16 4 Slot 4
Byte 17 8 7 6 5 Slot 5 to 8
Byte 18 12 11 10 9 Slot 9 to 12
Byte 19 16 15 14 13 Slot 13 to 16
Byte 20 20 19 18 17 Slot 17 to 20
Byte 21 24 23 22 21 Slot 21 to 24
Commissioning and Diagnostics
7.13 Diagnostics with STEP 7 with PROFIBUS
ET 200iSP
206 Operating Instructions, 11/2022, A5E00247483-AK
