Potential ET 200iSP

Potential auxiliary power

Potential network interface

Potential I/O

Figure 6-3 Potentials for ET 200iSP

For IM 152-1PN, no further potentials are required.

6.4 Wiring the ET 200iSP

6.4.1 Wiring Rules for the ET 200iSP

DANGER

Reviewing regulations

When laying cables and wiring, adhere to the installation regulations in accordance with EN

60079-14 and any regulations speci󹪝c to your country.

When operating the ET 200iSP in areas with combustible dust (zone 21, zone 22), you must

also comply with EN 61241-14.

Wiring

6.4 Wiring the ET 200iSP

ET 200iSP

Operating Instructions, 11/2022, A5E00247483-AK 125
