Quan

tity

Article Article number (Sie‐

mens)

Required for the con󹪝gura‐

tion variant

PROFINET IO PROFIBUS DP

2 8 DI NAMUR 6ES7131-7RF00-0AB0 YES YES

3 4 DO DC17.4V/27mA shut down "H" 6ES7132-7RD11-0AB0 YES YES

2 NAMUR sensor for example, BERO 3RG

4612-1NA00

YES YES

1 1-wire On button commercially available YES YES

3 LEDs with series resistor commercially available YES YES

1 Universal rack 6ES7400-1TA01-0AA0 YES YES

1 Power supply module PS S7-400 6ES7407-0DA02-0AA0 YES YES

1 Central processing unit CPU S7-410-5H 6ES7410-5HX08-0AB0 YES YES

1 Screwdriver with 3 mm blade width commercially available YES YES

1 Screwdriver with 4.5 mm blade commercially available YES YES

1 Cutting tool for the DIN rails commercially available YES YES

1 Cable cutters and wire stripping tools commercially available YES YES

1 Tool for crimping wire-end ferrules commercially available YES YES

1 Cable for grounding mounting rails with 10 mm² cross-sec‐

tion with cable lug to 󹪝t M6, length to suit local situation

commercially available YES YES

1 Cable lug for M6 commercially available YES YES

1 Stranded wire with 1 mm² cross-section with matching fer‐

rules, form A, length 6 mm

commercially available YES YES

Commissioning guideline

3.3 Materials and Tools Required to Set Up the Example

ET 200iSP

40 Operating Instructions, 11/2022, A5E00247483-AK
