Page #271 background imageLoading...
Page #271 background image
Technical speci󹪝cations
Voltages, currents, electrical potentials
Power failure bu󹪜ering power bus
min. 0.25 ms
Voltage failure backup interface module
min. 15 ms
Power failure bu󹪜ering backplane bus
min. 0.25 ms
Insulation tested
between supply voltage and all output voltages
DC 600 V
Current consumption
from power supply L+
max. 4 A
2
Starting current inrush
for DC 24 V
24.8 A
Power loss of the module 20 W
3
Permitted input power Max. 78.6 W
Output current at ambient temperature up to prod‐
uct version 2 of Power Supply PS
from -20 °C to +60 °C with horizontal mounting
and
-20 °C to +40 °C with all other mounting posi‐
tions
max. 5 A
from +60 °C to +70 °C with horizontal mounting
Max. 3.5 A
Output current at ambient temperature as of prod‐
uct version 3 of Power Supply PS
from -20 °C to +70 °C with horizontal mounting
and
-20 °C to +50 °C with all other mounting posi‐
tions
max. 5 A
Status, interrupts, diagnostics
Status display Yes (on interface module)
Interrupts No
Diagnostic functions
Group error display
No
Diagnostic information can be read
Ys (via interface module)
Safety data
UM = DC 250 V / AC 250 V
For additional information, see certi󹪝cate IECEx KEM 05.0004
https://www.iecex.com (https://www.iecex.com)
KEMA 04 ATEX2263 INMETRO UL-BR 12.0051
https://support.industry.siemens.com (https://support.industry.siemens.com)
1
up to product version 2: Tolerance rangeDC 20 V to 30 V, protection version 3 and higher Tolerance
range DC 19.2 V to 30 V.
Protection with automatic circuit breaker 6 A and tripping characteristic C (per ET 200iSP station)
2
Rated current: 3.3 A (for DC 24 V)
3
You can 󹪝nd additional information about power loss in the section Restricted Number of Connectable
Electronics Modules (Page 70)
Power Supply
11.1 Power supply PS 24 VDC
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 271
