Article number 6ES7152-1BA00-0AB0
Diagnostics function Yes
Alarms
• acyclic function, interrupts
Yes
• acyclic function, parameters
Yes
Diagnostics indication LED
• RUN LED
Yes; green LED
• ERROR LED
Yes; red LED
• MAINT LED
Yes; Yellow LED
• LINK LED
Yes; green LED
• Monitoring of the supply voltage (PWR-LED)
Yes; green LED
• Bus fault BF (red)
No
• Group error SF (red)
No
• Monitoring 24 V voltage supply ON (green)
No
Potential separation
between supply voltage and electronics No
Standards, approvals, certicates
CE mark Yes
UKCA mark No
Use in hazardous areas
• ATEX marking
II 2 G Ex ib IIC T4 Gb and I M2 Ex ib I Mb
• ATEX certicate
DEKRA 22ATEX0036
• IECEx
Yes; IECEx DEK 22.0020
• EAC Ex
No
Ambient conditions
Ambient temperature during operation
• horizontal installation, min.
-20 °C
• horizontal installation, max.
70 °C
• vertical installation, min.
-20 °C
• vertical installation, max.
50 °C
Ambient temperature during storage/transpor‐
tation
• min.
-40 °C
• max.
70 °C
Altitude during operation relating to sea level
• Ambient air temperature-barometric pres‐
sure-altitude
Up to max. 2 000 m
Relative humidity
• Operation, max.
95 %
Dimensions
Width 30 mm
Height 190 mm
Depth 130 mm
Network interface module
12.1 PROFINET interface module IM 152-1PN
ET 200iSP
280 Operating Instructions, 11/2022, A5E00247483-AK
