Page #300 background image
Technical speci󹪝cations
Article number 6ES7131-7RF00-0AB0
General information
Product type designation 8DI NAMUR
Input current
Current consumption, typ. 80 mA
from supply voltage L+, max. 90 mA
Digital inputs
Number of digital inputs 8
Input current
for signal "0", max. (permissible quiescent
current)
1.2 mA
for signal "1", min.
2.1 mA
Input delay (for rated value of input voltage)
for standard inputs
at "0" to "1", min.
2.8 ms
at "0" to "1", max.
3.5 ms
at "1" to "0", min.
2.8 ms
at "1" to "0", max.
3.5 ms
Cable length
shielded, max.
500 m
Encoder
Number of connectable encoders, max. 8
Connectable encoders
NAMUR encoder
Yes
Interrupts/diagnostics/status information
Diagnostics function Yes
Alarms
Diagnostic alarm
Yes; Parameterizable
Hardware interrupt
No
Diagnoses
Diagnostic information readable
Yes
Short-circuit
Yes; R load < 150 ohms with NAMUR sensor/sensor
and NAMUR changeover contact/sensor to DIN
19234
Diagnostics indication LED
Group error SF (red)
Yes
Status indicator digital input (green)
Yes
Integrated Functions
Frequency measurement Yes; (Gate time) 50 ms; 200 ms; 1 s
Number of frequency meters
2
Potential separation
Potential separation digital inputs
between the channels
No
Digital electronic modules
13.1 Digital electronics module 8 DI NAMUR
ET 200iSP
300 Operating Instructions, 11/2022, A5E00247483-AK
