Siemens SIMATIC ET 200iSP User Manual

Technical speci󹪝cations
Article number 6ES7134-7TD50-0AB0
General information
Product type designation 4AI I 4WIRE HART
Input current
Current consumption, typ. 27 mA
from supply voltage L+, max. 30 mA
Power loss
Power loss, typ. 0.4 W
Analog inputs
Number of analog inputs 4
permissible input current for current input (de‐
struction limit), max.
50 mA
Cycle time (all channels) max. 120 ms; 30 ms basic conversion time x4 channels
with 60 Hz, 50 Hz interference frequency suppres‐
sion
Technical unit for temperature measurement ad‐
justable
Yes
Input ranges (rated values), currents
• 4 mA to 20 mA
Yes
– Input resistance (4 mA to 20 mA)
295 Ω
Cable length
• shielded, max.
500 m
Analog value generation for the inputs
Measurement principle integrating (Sigma-Delta)
Integration and conversion time/resolution per
channel
• Resolution with overrange (bit including
sign), max.
12 bit; + sign
• Integration time, parameterizable
Yes
• Basic conversion time, including integration
time (ms)
30 ms
• Interference voltage suppression for interfer‐
ence frequency f1 in Hz
50 / 60 Hz
Smoothing of measured values
• parameterizable
Yes; in 4 stages
• Step: None
Yes; 1x cycle time
• Step: low
Yes; 4x cycle time
• Step: Medium
Yes; 32x cycle time
• Step: High
Yes; 64x cycle time
Encoder
Connection of signal encoders
• for current measurement as 4-wire transduc‐
er
Yes
Errors/accuracies
Analog electronic modules
14.3 Analog electronics module 4 AI I 4WIRE HART
ET 200iSP
354 Operating Instructions, 11/2022, A5E00247483-AK
