Siemens SIMATIC ET 200iSP

Technical speci󹪝cations
Voltages, currents, electrical potentials
Transmitter power supply No
Electrical isolation
• Between channels and power bus
Yes
Formation of analog values
• Cycle time in ms
Number of active channels per module x
basic conversion time
Noise suppression, error limits
Interference voltage suppression for f = n x (f1±1%), f1 = interference frequency
• Series mode interference (peak value of disturbance <
rated input range)
min 70 dB
Crosstalk between inputs min. - 50 dB
Status, interrupts, diagnostics
Diagnostic functions
• Group error display
Red "SF" LED
Monitoring for
• Wire break
I < 3.6 mA
Safety information
U
o
= 0.9 V
I
o
= 0.8 mA
P
o
= 0.2 W
C
o
= 1000 μF
L
o
= 1000 mH
For additional C
o
/ L
o
combinations, see certi󹪝cate IECEx KEM 05.0007
https://www.iecex.com (https://www.iecex.com)
KEMA 04 ATEX124587
INMETRO UL-BR 12.0074
https://support.industry.siemens.com (https://support.industry.siemens.com)
Data for selecting a sensor
Input ranges (rated values) / input resistance
• Current
0 to 20 mA / 360 Ω to 20 mA
4 to 20 mA / 360 Ω at 20 mA
Permissible input current for current input (destruction
limit)
50 mA
Connection of signal generators supported
• for current measurement
as 4-wire transmitter
supported
1
Time taken to reach 63 % of the jump value
Analog electronic modules
14.3 Analog electronics module 4 AI I 4WIRE HART
ET 200iSP
356 Operating Instructions, 11/2022, A5E00247483-AK
