Technical speci󹪝cations
Linearity error (relative to the input range) ± 0.015%
Repeatability (in settled state at 25 °C, relative to input
range)
± 0.01 %
Status, interrupts, diagnostics
• Group error display
Red "SF" LED
Monitoring for
• Wire break
R > 2 kΩ
Safety information
U
o
= 5.9 V
I
o
= 24 mA
P
o
= 36 mW
C
o
= 43 μF
L
o
= 50 mH
For additional C
o
/ L
o
combinations, see certi󹪝cate IECEx KEM 05.0009
https://www.iecex.com (https://www.iecex.com)
KEMA 04 ATEX1247 INMETRO UL-BR 12.0069
https://support.industry.siemens.com (https://support.industry.siemens.com)
Data for selecting a sensor
Input ranges (rated values) / input resistance
• Resistance
600 Ω / 1000 Ω absolute / min 2 MΩ
• Resistance thermometer
Pt100 / min 2 MΩ; Ni100 / min 2 MΩ
Connection of signal generators
• For resistance measurement / RTD
4-wire connection
3-wire connection
2
2-wire connection
supported
supported
supported
Characteristics linearization Yes
• of resistance thermometers
Technical unit of data formats Can be set
1
Time taken to reach 63 % of the jump value
2
With compensation of the connecting cables
Approvals
ATEX II 2 G(1) GD and I M2
Ex ib [ia Ga] IIC T4 Gb
Ex ib [ia IIIC Da] IIC T4 Gb
Ex ib [ia/] I Mb
KEMA 04 ATEX 1247
0344
IECEx IECEx KEM 05.0009
INMETRO
R
#3
0$1
BR-Ex ib [ia Ga] IIC T4 Gb
BR-Ex ib [ia IIIC Da] IIC T4 Gb
BR-Ex ib [ia] I Mb
Analog electronic modules
14.4 Analog electronics module 4 AI RTD
ET 200iSP
362 Operating Instructions, 11/2022, A5E00247483-AK
