You can obtain the above documentation from the PNO (PROFIBUS User Organization) on the
Internet PROFIBUS (https://www.pro󹪝bus.com).
Table 14-38 HART data records
Data record
number
Read / write Size in bytes Designation
148 read 13 Directory process data
DR information (data record directory): This data record contains the data record numbers (index) of all
HART data records and information on the con󹪝guration limits and for revision.
149 read 3 HMD Feature Parameter Process Data
HART feature 󹪞ags: This data record describes which optional HART functions are supported.
129 Read / write 6 HMD Parameter Process Data
HART parameters: This data record contains the parameters for the HART master. The status of the parameter
assignment can be evaluated during the reading of the data record. There are no manufacturer speci󹪝c
parameters for the analog modules with HART.
140 Read / write 12 HART Mapping data record
HART mapping data record: This data record contains the assignment of the individual HART measured
values to the channels of the module.
80 Write 75 HART Request Write Process Data
Letterbox channel 0: This data record contains the transfer data for the command from the client to the HART
󹪝eld device (on channel 0).
81 read 75 HART Response Read Process Data
Letterbox channel 0: This date record contains the transfer data for the response from the HART 󹪝eld device
(on channel 0) to the client.
82 Write 75 HART Request Write Process Data
Letterbox channel 1: This data record contains the transfer data for the command from the client to the HART
󹪝eld device (on channel 1).
83 read 75 HART Response Read Process Data
Letterbox channel 1: This date record contains the transfer data for the response from the HART 󹪝eld device
(on channel 1) to the client.
84 Write 75 HART Request Write Process Data
Letterbox channel 2: This data record contains the transfer data for the command from the client to the HART
󹪝eld device (on channel 2).
85 read 75 HART Response Read Process Data
Letterbox channel 2: This date record contains the transfer data for the response from the HART 󹪝eld device
(on channel 2) to the client.
86 Write 75 HART Request Write Process Data
Letterbox channel 3: This data record contains the transfer data for the command from the client to the HART
󹪝eld device (on channel 3).
87 read 75 HART Response Read Process Data
Letterbox channel 3: This date record contains the transfer data for the response from the HART 󹪝eld device
(on channel 3) to the client.
You can 󹪝nd more information on the HART operating data records in section "HART operating
data records (Page 451)".
Analog electronic modules
14.10 Basics of HART
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 399
