HART protocol
error during re‐
sponse
Meaning Explanation
5 Response error Bit 0 = 1: GAP timeout
Bit 1 = 1: Receive bu󹪜er over󹪞ow
Bit 2 = 1: Timeout
Bit 3 = 1: Checksum error
Bit 4 = 1: Framing error
Bit 5 = 1: Over󹪞ow error
Bit 6 = 1: Parity error
Bit 7 = 1: Reserved
6 Query rejected 0: Not speci󹪝ed
1: Short format (compact format) not supported
2: SHC not supported
3: Impermissible command
4: No resources
5: Channel in standby mode
1
6 to 127: Reserved
128 to 255: Manufacturer-speci󹪝c
7 Pro󹪝le query rejected 0: Not speci󹪝ed (not supported)
8 Manufacturer-speci󹪝c
query rejected
0: Not speci󹪝ed (not supported)
1
An external HART request was refused because the channel is not the active channel of a redundancy
pair. The request must be sent to the connected 󹪝eld device via the partner module
Example of HART programming (HART command interface)
For the HART channel 0, the command 01 is to be sent in the transparent message format to the
HART 󹪝eld device with the address "98 CF 38 84 F0".
A positive edge at input 4.0 of a digital input module leads to the writing of the HART command.
The following assumptions are made:
• The module address of the I/O module is 512 (200
H
)
• The data record is stored in DB80: starting from address 0.0, length of 11 bytes.
• The DB80 (request data record for channel 0) in this example consists of 11 bytes
Explanation
U E 4.0
FP M 101.0
= M 104.0
m2: CALL SFB53, DB53
REQ :=M104.0 Write request
ID :=DW#16#200
INDEX :=80
Module address
Data record number 80
LEN :=11 Length 11 bytes
Appendix
A.6 HART operating data records
ET 200iSP
456 Operating Instructions, 11/2022, A5E00247483-AK
