Siemens SIMATIC ET 200SP System Manual

Wiring
6.13 Inserting I/O modules / motor starters and BU covers
Distributed I/O system
116 System Manual, 09/2019, A5E03576849-AJ
Reference
You can find additional information on the PROFIBUS FastConnect bus connector in the
corresponding product information on the Internet
(http://support.automation.siemens.com/WW/view/en/58648998
).
6.13 Inserting I/O modules / motor starters and BU covers
Introduction
● You insert the I/O modules on the BaseUnits. The I/O modules are self-coding and type-
coded.
● You insert the PotDis-TerminalBlocks on the PotDis-BaseUnits.
● You insert the BU covers on BaseUnits whose slots are not equipped with I/O
modules/PotDis-TerminalBlocks.
● You insert the BU covers on BaseUnits whose slots have been reserved for future
expansion (as empty slots).
● The BU covers for motor starters serve as touch protection covers for unoccupied slots.
The BU covers have a holder for the reference identification label on the inside. For future
expansion of the ET 200SP, remove the reference identification label from the holder and
insert it into the final I/O module.
It is not possible to attach a reference identification label to the BU cover itself.
There are three versions:
– BU cover with a width of 15 mm
– BU cover with a width of 20 mm
– BU cover with a width of 30 mm (for motor starters)
Requirement
Refer to chapter "Application planning (Page 33)".

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
