Application planning

4.6 Configuration examples for potential groups

Distributed I/O system

System Manual, 09/2019, A5E03576849-AJ

59

4.6 Configuration examples for potential groups

4.6.1 Configuration examples with BaseUnits

Table 4- 5 Configuration examples with BaseUnits

BaseUnits

Configuration

BU15-

P16+A0+2D

BU15-

P16+A0+2B

BU15-

P16+A0+2D

BU15-

P16+A0+2B

BU20-

P12+A0+0B
