Configuration control (option handling)
10.2 Creating the control data record
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
175
136 First slot of ET 200AL (slot
67)
Slot assignment in the
station option
Contains information on which ET 200AL
module is inserted in which slot.
The value that you need to enter in the
corresponding byte depends on the fol-
lowing rule:
• If the module exists in the station
option, enter the slot number of the
module.
• If the module does not exist in the
station option, enter 0.
166 Last slot of ET 200AL (slot
Slot assignment in the
167 Reserved
* The server module must be present in the station option and must not be marked as empty slot (BU cover).
10.2.3 Control data record for an interface module
Slot assignment
The following table shows the possible slots for the various modules for an
ET 200SP interface module:
Table 10- 3 Slot assignment
Interface module 0 The interface module (slot 0) is not an element of the configu-
ration control, but instead controls this.
Station extension
1 For mixed configuration with ET 200AL modules, BA-Send is
ET 200SP I/O module
Downstream from the interface module
1 - 32 for IM 155-6 PN ST,
1 - 64 for IM 155-6 PN HF,
Server module
The server module completes the configuration of the
ET 200SP station after the last I/O module.
1 - 33 for IM 155-6 PN ST,
1 - 65 for IM 155-6 PN HF,
ET 200AL I/O module
For mixed configuration with ET 200AL modules
66 - 81
for IM 155-6 PN ST,
IM 155-6 PN HF,
