Wiring
6.6 Wiring rules
Distributed I/O system
98 System Manual, 09/2019, A5E03576849-AJ
6.6 Wiring rules
Wiring rules for the CPU/interface module and BaseUnits for I/O modules
Wiring rules for ...
CPU/interface module (supply
voltage)
BaseUnits
(push-in terminal)
Permitted cable cross-sections of solid cables (Cu)
0.2 to 2.5 mm
2
AWG
*
: 24 to 13
Permitted cable
cross-sections of
flexible cables (Cu)
Without end sleeve
0.2 to 2.5 mm
2
AWG
*
: 24 to 13 AWG*: 24 to 14
With end sleeve (with plas-
tic sleeve)
***
0.25 mm to 1.5 mm
2**
0.14 mm to 1.5 mm
2
AWG
*
: 24 to 16 AWG
*
: 26 to 16
With TWIN end sleeve
***
0.5 mm to 1 mm
2
0.5 to 0.75 mm
2
(see below)
AWG
*
: 20 to 17
AWG
*
: 20 to 18
Stripping length of the wires
8 to 10 mm
End sleeves in accordance with DIN 46228 with
plastic sleeve
***
8 and 10 mm long
* AWG: American Wire Gauge
** End sleeves without plastic sleeve: 0.25 to 2.5
mm
2
/AWG: 24 to 13
*** See note on end sleeves
Note the following for BaseUnits with function version < FS10:
Note
End sleeves
Optimum results with respect to a high
-quality and permanent electrical connection with
maximum conductor pull forces at the same time can be achieved by using crimping dies
,
preferably with smooth surfaces, which ar
e provided, for example, with rectangular and
trapezoidal crimp cross
-sections.
Crimping dies with a pronounced wave profile are unsuitable.
