Siemens SIMATIC ET 200SP System Manual

Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
192
Commissioning
11
11.1 Overview
Introduction
This section includes information on the following topics:
● Commissioning the ET 200SP distributed I/O system on the PROFINET IO
● Commissioning the ET 200SP distributed I/O system on the PROFIBUS DP
● Startup of the ET 200SP distributed I/O system with empty slots
● Removing/inserting the SIMATIC memory card
● Operating modes of the CPU
● CPU memory reset
● Reassigning parameters during operation
● Identification and maintenance data
Commissioning requirements
Note
Performing tests
Y
ou must ensure the safety of your plant. You therefore need to run a complete functional
test and make the necessary safety checks before the final commissioning of a plant.
Also allow for any possible foreseeable errors in the tests. This avoids end
angering persons
or equipment during operation.
PRONETA
With SIEMENS PRONETA (PROFINET network analysis), you analyze the system network
during commissioning. PRONETA features two core functions:
● The topology overview independently scans PROFINET and all connected components.
● The IO check is a fast test of the wiring and the module configuration of a system.
You can find SIEMENS PRONETA on the Internet
(http://support.automation.siemens.com/WW/view/en/67460624
).

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
