Siemens SIMATIC ET 200SP System Manual

Wiring
6.12 Connecting interfaces for communication
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
113
6.12 Connecting interfaces for communication
Connect the communication interfaces of the ET 200SP distributed I/O system using the
standardized connector or directly. If you want to prepare communication cables yourself,
the interface assignment is specified in the manuals of the corresponding modules. Observe
the mounting instructions for the connectors.
Detailed information on the available BusAdapters and the procedure for connecting
PROFINET IO to the CPU/interface module is available in the BusAdapter
(https://support.industry.siemens.com/cs/ww/en/view/109751716
) manual.
6.12.1 Connecting PROFINET IO (port P3) to the CPU
Introduction
You use the RJ-45 bus connector to connect PROFINET IO (port P3) directly to the CPU.
Required accessories
● Cable ties with standard width of 2.5 mm or 3.6 mm for strain relief
● Please observe the specifications in the PROFINET Installation Guide
(http://www.profibus.com
).
Mounting the bus connector
Mount the PROFINET connector in accordance with the instructions in the PROFINET
Installation Guide (http://www.profibus.com
).

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
