Basics of program execution
8.2 Asynchronous instructions
Distributed I/O system
150 System Manual, 09/2019, A5E03576849-AJ
Extended instructions: maximum number of concurrently running jobs
Table 8- 2 Maximum number of concurrently running jobs for asynchronous extended instructions and lower-level instruc-
tions used
Extended instructions
CPU 1510SP-1 PN
CPU 1510SP F-1 PN
CPU 1512SP-1 PN
CPU 1512SP F-1 PN
Distributed I/O
RDREC
20
RD_REC
10
WRREC 20
WR_REC
10
D_ACT_DP
8
ReconfigIOSystem
uses RDREC, WRREC, D_ACT_DP,
DPSYC_FR
2
DPNRM_DG
8
DP_TOPOL
1
ASI_CTRL
uses RDREC, WRREC
PROFIenergy
PE_START_END
uses RDREC, WRREC
PE_CMD
uses RDREC, WRREC
PE_DS3_Write_ET200S
uses RDREC, WRREC
PE_WOL
uses RDREC, WRREC, TUSEND, TURCV, TCON, TDISCON
Module parameter assignment
RD_DPAR
10
RD_DPARA
10
RD_DPARM
10
WR_DPARM
10
Diagnostics
Get_IM_Data
10
GetStationInfo
10
Recipes and data logging
RecipeExport
10
RecipeImport
10
DataLogCreate
10
DataLogOpen
10
DataLogWrite
10
DataLogClear
10
DataLogClose
10
DataLogDelete
10
DataLogNewFile
10
Data block functions
CREATE_DB
10
READ_DBL
10

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
