Siemens SIMATIC ET 200SP System Manual

Protection
9.5 Copy protection
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
165
4. Activate the option "Serial number is inserted when downloading to a device or a memory
card" if the serial number is to be inserted automatically during the uploading process
(dynamic binding). Assign a password using the "Define password" button to link the use
of a block additionally to the input of a password.
Activate the option "Enter serial number" if you want to manually bind the serial number of
the CPU or the SIMATIC memory card to a block (static binding).
5. You can now set up the know-how protection for the block in the "Know-how protection"
area.
Note
If you download a copy
-protected block to a device that does not match the specified
serial number, the entire down
load operation will be rejected. This means that blocks
without cop
y protection will also not be downloaded.
Removing copy protection
To remove copy protection, follow these steps:
1. Remove any existing know-how protection.
2. Open the properties of the block in question.
3. Select the "Protection" option under "General".
4. In the "Copy protection" area, select the "No binding" entry from the drop-down list.
Figure 9-9 Removing copy protection

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
