Commissioning
11.2 Commissioning the ET 200SP for PROFINET IO
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
195
Commissioning procedure
To commission the ET 200SP distributed I/O system CPU as an IO controller for
PROFINET IO, we recommend the following procedure:
Table 11- 1 Procedure for commissioning the ET 200SP CPU as an IO controller for PROFINET IO
Section Installation (Page 63)
2 Connecting ET 200SP
• Supply voltages
• PROFINET IO
• Sensors and actuators
Section Wiring (Page 86)
3 Inserting a SIMATIC memory card in the IO
Section Removing/inserting a SIMATIC
memory card on the CPU (Page 205)
Configuring the IO controller
1
Section Configuring (Page 131)
Checking the protective measures
6 Switching on supply voltages for the IO
controller
CPU 15xxSP-1 PN
(
http://support.automation.siemens.com/
WW/view/en/90466439/133300) manual
Switching on supply voltages for IO devices
Documentation of the IO device
8 Downloading the configuration to the IO
STEP 7 online help
9 Switching IO controller to RUN mode CPU 15xxSP-1 PN
(http://support.automation.siemens.com/
WW/view/en/90466439/133300) manual
10 Checking LEDs CPU 15xxSP-1 PN
(http://support.automation.siemens.com/
WW/view/en/90466439/133300) manual
11 Testing inputs and outputs The following functions are helpful: Mon-
itoring and modifying tags, testing with
program status, forcing, controlling the
outputs. See section Test and service
1
The IO devices are configured with the IO controller.
