Siemens SIMATIC ET 200SP System Manual

Commissioning
11.11 Identification and maintenance data
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
229
Identification data
Access
Default
Explanation
• IM_SWRevision_Internal_
Change
(1 byte) 00 - FF
H
IM_REVISION_COUNTER Read (2 bytes) 0000
H
Provides information about parameter
changes on the module
(not used)
IM_PROFILE_ID
Read (2 bytes)
0000
H
Generic Device
IM_PROFILE_SPECIFIC_TYPE Read (2 bytes)
0005
H
Interface modules/BusAdapters
0003
H
I/O modules and motor starters
0001
H
CPU
IM_VERSION
Read
0101
H
Provides information on the version of
the identification data
(0101
H
= Version 1.1)
• IM_Version_Major
(1 byte)
• IM_Version_Minor
(1 byte)
IM_SUPPORTED Read (2 bytes) 000E
H
Provides information about the available
identification data (I&M1 to I&M3)
Maintenance data 1: (data record index AFF1 hex)
IM_TAG_FUNCTION Read/write (32
bytes)
- Enter a module identifier here that is
unique plant-wide.
IM_TAG_LOCATION Read/write (22
bytes)
- Enter the installation location of the mod-
ule here.
Maintenance data 2: (data record index AFF2 hex)
IM_DATE Read/write (16
bytes)
YYYY-MM-DD HH:MM Enter the installation date of the module
here.
Maintenance data 3: (data record index AFF3 hex)
IM_DESCRIPTOR Read/write (54
bytes)
- Enter a comment describing the module.
Reading I&M data records with data record 255 (distributed via PROFIBUS DP)
The modules support standardized access to identification data via DS 255 (index 65000 to
65003). For further information on the DS 255 data structure, refer to the specifications of the
Profile Guidelines Part 1: Identification & Maintenance Functions, Order No.: 3.502,
Version 2.1, May 2016

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
