Siemens SIMATIC ET 200SP System Manual

Application planning
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
35
Selecting a BaseUnit
I/O module
(example)
Examples of suitable I/O modules for BU types
I/O module (example)
BaseUnit
BU type
C1
(BU..B, dark-colored
BaseUnit)
F-CM AS-i Safety ST
• 6ES7...
C1
• Up to 30 V DC
• 20 mm wide
F-CM AS-i Safety ST
(3RK7136-6SC00-0B
C1
)
BU20-P6+A2+4B
(6ES7193-6BP20-0B
C1
)
BU type
D0
AI Energy Meter
• 6ES7...
D0
• Up to 400 V AC/
480 V AC
• 20 mm wide
AI Energy Meter 480VAC
ST
(6ES7134-6PA20-0B
D0
)
BU20-P12+A0+0B
(6ES7193-6BP00-0B
D0
)
BU type
F0
F-
RQ 1×24VDC/24..230
VAC/5A
• 6ES7...
F0
• Up to 230 V AC
• 20 mm wide
F-
RQ 1×24VDC/24..230VA
C/5A
(6ES7136-6RA00-0B
F0
)
BU20-P8+A4+0B
(6E7193-6BP20-0B
F0
)
BU type
U0
DQ 4×24...230VAC/2
A HF
• 6ES7...
U0
• Up to
400 V AC/480 V A
C
• 20 mm wide
DQ 4×24...230VAC/2A HF
(6ES7132-6FD00-0C
U0
)
BU20-P16+A0+2D
(6E7193-6BP00-0B
U0
)
* For compensation of the reference junction temperature for thermocouples. BU type A1 is required if
you measure the reference junction temperature with an internal temperature sensor or if you need
the additional 2×5 terminals.
If you use the internal reference junction temperature with BU type A1, ensure an even tempera-
ture distribution at the terminals. The specified accuracy of the utilized analog module is then ad-
hered to. If necessary, you can increase the accuracy via user calibration.
** Analog mod
ules
with and without
temperature measurement can also be plugged into BU type A0.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
