Installation
5.1 Basics
Distributed I/O system
64 System Manual, 09/2019, A5E03576849-AJ
Mounting rail
Mount the ET 200SP distributed I/O system on a mounting rail in accordance with EN 60715
(35 × 7.5 mm or 35 × 15 mm).
You need to ground the mounting rail separately in the control cabinet. Exception: If you
install the rail on grounded, zinc-plated mounting plates, there is no need to ground the rail
separately.
Note
If the ET
200SP distributed I/O system is exposed to vibration and shock loads, both
ends of
the ET
200SP system assembly must be mechanically fixed to the mounting rail (e.g using
8WA1010
-1PH01 ground terminals). This measure prevents the ET 200SP distributed I/O
system from shifting to the side.
Note
If the ET
200SP distributed IO system is exposed to increased vibrations and shock, we
recommend that you screw the mounting rail to the mounting surface at intervals of approx.
200 mm.
The following are suitable surfaces for the mounting rails:
● Steel strip in accordance with Appendix A of EN 60715 or
● Tinned steel strip. We recommend these in conjunction with the mounting rails in the
section Accessories/spare parts (Page 291).
Note
If you use mounting rails from other manufacturers, make sure that they have the
required properties for your ambient climatic conditions.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
