Siemens SIMATIC S7-1500 Automation System User Manual

Commissioning
8.6 Identification and maintenance data
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
113
Table 8- 3 Record structure for I&M identification data
Identification data Access Example Explanation
Identification data 0: (record index AFF0
H
)
VendorIDHigh read (1 bytes) 0000
H
VendorIDLow read (1 bytes) 002A
H
Vendor name
(002A
H
= SIEMENS AG)
Order_ID read (20 bytes) 6ES7516-3AN00-0AB0 Order number of the module
(e.g. CPU 1516-3 PN/DP)
IM_SERIAL_NUMBER read (16 bytes) - Serial number (device-specific)
IM_HARDWARE_REVISION read (2 bytes) 1 corresponds to hardware version
(e.g. 1)
IM_SOFTWARE_REVISION read Firmware version
• SWRevisionPrefix
(1 byte) V
• IM_SWRevision_Functional_
Enhancement
(1 byte) 0000
H
- 00FF
H
• IM_SWRevision_Bug_Fix
(1 byte) 0000
H
- 00FF
H
• IM_SWRevision_Internal_
Change
(1 byte) 0000
H
- 00FF
H
Provides information about the firmware
version of the module (e.g. V1.0.0)
IM_REVISION_COUNTER read (2 bytes) 0000
H
Provides information about parameter
changes on the module
(not used)
IM_PROFILE_ID read (2 bytes) 0000
H
Generic Device
0001
H
CPU IM_PROFILE_SPECIFIC_TYPE read (2 bytes)
0003
H
I/O modules
IM_VERSION read
• IM_Version_Major
(1 byte)
• IM_Version_Minor
(1 byte)
0101
H
Provides information on the ID data
version
(0101
H
= Version 1.1)
IM_SUPPORTED read (2 bytes) 000E
H
provides information about the available
identification and maintenance data
(I&M1 to I&M3)
Maintenance data 1: (Record index AFF1
H
)
IM_TAG_FUNCTION read/write
(32 bytes)
- Enter an identifier for the module here,
that is unique plant-wide.
IM_TAG_LOCATION read/write
(22 bytes)
- Enter the installation location of the
module here.
Maintenance data 2: (Record index AFF2
H
)
IM_DATE read/write
(16 bytes)
YYYY-MM-DD HH:MM Enter the installation date of the module
here.
Maintenance data 3: (Record index AFF3
H
)
IM_DESCRIPTOR read/write
(54 bytes)
- Enter a comment about the module here.

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
