Technical specifications
15.5 Information on insulation tests, protection class, degree of protection and rated voltage
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
173
15.5 Information on insulation tests, protection class, degree of protection
and rated voltage
Insulation
The insulation is designed in accordance with the requirements of EN 61131-2: 2007.
Note
For modules with 24 VDC supply voltage, the electrical isolation is designed for max.
60 VAC / 75 VDC and basic insulation is designed according to EN 61131-2: 2007.
Contamination level/overvoltage category according to IEC 61131-2: 2007
Pollution degree 2
Overvoltage category: II
Protection class in accordance with IEC 61131-2: 2007
Protection class I or III, depending on module type
Degree of protection IP20
Degree of protection IP20 in accordance with IEC 60529 for all modules of the S7-1500
automation system, i.e.:
Protection against contact with standard test finger
Protection against foreign objects with diameters in excess of 12.5 mm
No protection against water
