Dimension drawings
A.2 Dimension drawing of CPU, 35 mm wide
S7-1500 Automation System
178 System Manual, 01/2013, A5E03461182-01
A.2 Dimension drawing of CPU, 35 mm wide
In this appendix you will find the dimension drawing of the CPU installed on a mounting rail,
as well as a dimension drawing with open front cover. Always observe the specified
dimensions for installation in cabinets, control rooms, etc.
Figure A-6 Dimension drawing of CPU (35 mm wide), front and side views
ෘa
Figure A-7 Dimension drawing of CPU (35 mm wide), side view with open front cover
Note
Minimum clearances
Observe the minimum clearances of 25 mm, above and below the mounting rail, as
described in the chapterMounting (Page 39).
