S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
193
Accessories/spare parts
B
Accessories for the S7-1500 automation system
Table B- 1 Accessories for the S7-1500 automation system
Description Order number
Mounting rail
• Mounting rail, 160 mm (with drill holes)
6ES7590-1AB60-0AA0
• Mounting rail, 482 mm (with drill holes)
6ES7590-1AE80-0AA0
• Mounting rail, 530 mm (with drill holes)
6ES7590-1AF30-0AA0
• Mounting rail, 830 mm (with drill holes)
6ES7590-1AJ30-0AA0
• Mounting rail, 2000 mm (without drill holes)
6ES7590-1BC00-0AA0
PE connection element for mounting rail, 2000 mm (spare part),
20 units
6ES7590-5AA00-0AA0
Front connector (incl. four potential bridges, cable tie, and a single labeling strip)
• Screw-type terminals, 40-pin
6ES7592-1AM00-0XB0
4-pole connection plug for supply voltage (spare part), 10 units 6ES7193-4JB00-0AA0
DIN A4 labeling sheet (10 x for labeling the I/O modules)
• pre-perforated, AI gray
6ES7592-2AX00-0AA0
U connector (spare part), 5 units 6ES7590-0AA00-0AA0
I/O shielding set (consists of: power supply element, shielding
bracket, and shield clamp), (spare part), 5 units
6ES7590-5CA00-0AA0
U connector (spare part), 10 units 6ES7590-5BA00-0AA0
70 mm display for CPU (spare part) 6ES7591-1BA00-0AA0
35 mm display for CPU (spare part) 6ES7591-1AA00-0AA0
Power cable connector with coding element for power supply
module (spare part), 10 units
6ES7590-8AA00-0AA0
Potential bridge for front connector (spare part), 20 units 6ES7592-3AA00-0AA0
Universal front cover for I/O modules (spare part), 5 units 6ES7528-0AA00-7AA0
Consists of:
• 5 x front cover
• 5 x front labeling strip (per module order number)
• 5 x wiring plan (per module order number)
Industrial Ethernet FastConnect RJ45 plug 180, 1 unit 6GK1901-1BB10-2AA0
Industrial Ethernet FastConnect RJ45 plug 180, 10 units 6GK1901-1BB10-2AB0

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
