Siemens SIMATIC S7-1500 Automation System User Manual

S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
129
Test functions and fault resolution
10
10.1 Test functions
Introduction
You have the option of testing the operation of your user program on the CPU. You can then
monitor signal states and values of tags and can assign values to tags to simulate specific
situations in the running of the program.
Note
Using test functions
The use of test functions can influence the program execution time and thus the cycle and
response times of the controller to a slight extent (a few milliseconds).
Requirements
The following requirements must be met:
● There is an online connection to the relevant CPU.
● There must be an executable program in the CPU.
Test options
The following test options are available:
● Testing with program status
● Testing with a watch table
● Testing with a force table
● Testing with the LED flash test
● Testing with the trace and logic analyzer function
Testing with program status
The program status allows you to monitor the execution of the program. You can display the
values of operands and the results of logic operations (RLO) allowing you to recognize and
fix logical errors in your program.

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
