Dimension drawings
A.6 Dimension drawing of system power supply, 35 mm wide
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
183
A.6 Dimension drawing of system power supply, 35 mm wide
In this appendix you will find the dimension drawing of the system power supply installed on
a mounting rail, as well as a dimension drawing with open front cover. Always observe the
specified dimensions for installation in cabinets, control rooms, etc.
Figure A-14 Dimension drawing of system power supply (35 mm wide), front and side views
Figure A-15 Dimension drawing of system power supply (35 mm wide), side view with open front
cover
