Module overview
3.5 Analog output modules
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
25
3.5 Analog output modules
Overview of properties
The table below shows the essential properties of the analog output modules.
Table 3- 6 Analog output modules
Order no.: 6ES7532-5HD00-0AB0 6ES7532-5HF00-0AB0
Short description AQ 4xU/I ST AQ 8xU/I HS
Number of outputs 4 8
Resolution 16 bits (including sign) 16 bits (including sign)
Output type Voltage
Current
Voltage
Current
Electrical isolation between channels No No
Rated supply voltage 24 VDC 24 VDC
Diagnostic error interrupt Yes Yes
Isochronous operation supported No Yes
Reference
Further information on the technical specifications of the modules may be found in the
respective manuals.
3.6 System power supply modules
Overview of properties
The table below shows the essential properties of the system power supply modules.
Table 3- 7 System power supply modules
Order no.: 6ES7505-0KA00-0AB0 6ES7505-0RA00-0AB0 6ES7507-0RA00-0AB0
Short description PS 25W 24V DC PS 60W 24/48/60V DC PS 60W 120/230V AC/DC
Rated input voltage 24 VDC 24 VDC, 48 VDC, 60 VDC 120 VAC, 230 VAC
120 VDC, 230 VDC
Output power 25 W 60 W 60 W
Electrical isolation from the
backplane bus
Yes Yes Yes
Diagnostic error interrupt Yes Yes Yes
Reference
Further information on the technical specifications of the system power supply modules may
be found in the respective product manuals.

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
