Siemens SIMATIC S7-1500 Automation System User Manual

Commissioning
8.6 Identification and maintenance data
S7-1500 Automation System
112 System Manual, 01/2013, A5E03461182-01
8.6.2 Record structure for I&M data
Reading I&M records (centrally and distributed via PROFINET IO)
You can directly access specific identification data for a module using Read record
("RDREC" instruction). Under the associated record index you obtain the corresponding part
of the identification data.
The records are structured as follows:
Table 8- 2 Basic record structure for I&M identification data
Contents Length (bytes) Coding (hex)
Header information
BlockType 2 I&M0: 0020
H
I&M1: 0021
H
I&M2: 0022
H
I&M3: 0023
H
BlockLength 2 I&M0: 0038
H
I&M1: 0038
H
I&M2: 0012
H
I&M3: 0038
H
BlockVersionHigh 1 01
BlockVersionLow 1 00
Identification data
Identification data
(see table below)
I&M0/Index AFF0
H
: 54
I&M1/Index AFF1
H
: 54
I&M2/Index AFF2
H
: 16
I&M3/Index AFF3
H
: 54
-
-
-
-

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
