Dimension drawings
A.8 Dimension drawing of load power supply, 50 mm wide
S7-1500 Automation System
186 System Manual, 01/2013, A5E03461182-01
A.8 Dimension drawing of load power supply, 50 mm wide
In this appendix you will find the dimension drawing of the load power supply installed on a
mounting rail, as well as a dimension drawing with open front cover. Always observe the
specified dimensions for installation in cabinets, control rooms, etc.
Figure A-18 Dimension drawing of load current supply (50 mm wide), front and side views
Figure A-19 Dimension drawing of load current supply (50 mm wide), side view with open front cover
